Breakdown Metals
Breakdown Metals
Breakdown Metals writes the metal cost breakdown into the viewport as a text block: run the command, pick a point, and the table is placed there — each metal in the piece with its weight and cost, ready to sit on the report sheet next to the drawing.
.png)
The figures come from the setup in Breakdown Details: the metals it lists and the prices it applies are the ones configured there, so the text always matches the pricing side of the document.
See also Breakdown Gems, Breakdown Processes and Breakdown Extras for the other parts of the cost.
